IQ4 Hub Wireless Alarm System Kit with LCD Display, Built-in Wi-Fi and 4G Communication

Kit Includes:
1. QOLSYS IQ4 Hub Control Panel (IQPH3AG) – 1 pc.
2. PowerG Wireless PIR Motion Detector (PGP8914) – 1 pc.
3. PowerG Wireless Door/Window Contact (PGP8945) – 1 pc.

Technical Specifications – IQ4 Hub
Display
7-inch LCD touchscreen.
Resolution: 1024 × 600 pixels.
Brightness: 300 cd/m².
24-bit color (16.9 million colors).
Capacitive glass touchscreen with Touch & Swipe interface.
Operating System & Processor
Android 9 operating system with OTA firmware updates.
Qualcomm Snapdragon octa-core System-on-Module (SOM).
16 GB NAND Flash memory.

User Management
Up to 242 user codes (User roles include Dealer, Installer, Administrator, User, Guest, and Duress).
Connectivity
Dual-band Wi-Fi 802.11 a/b/g/n/ac (2.4 GHz & 5 GHz). Wi-Fi Access Point mode.
LTE Cat 4 cellular communicator.

Device Support
Z-Wave Plus (800 Series): Up to 137 Z-Wave Plus (800 Series) devices.
PowerG (915 MHz): Up to 128 PowerG wireless devices.
RF devices: Up to 128 RF devices (depending on regional model).
Bluetooth: Bluetooth Low Energy (BLE) 4.2.

Audio
4 W front-facing speaker.
Built-in 85 dB piezo siren.
MEMS microphone for voice control and audio streaming.

Status Indicators
Full-color RGB LED status indicator.

Power
7 VDC, 1000 mA power supply.
Rechargeable 3000 mAh lithium-ion backup battery. More than 24 hours of backup operation.

Tamper Protection
Dual tamper detection, Wall removal tamper, Smash & Grab protection.

Controls
Single physical Wake/Sleep button, Full touchscreen operation.

Dimensions
155 × 191 × 26 mm (6.1 × 7.5 × 1 in).
SmartMount wall bracket and tabletop stand included.

Environmental
Operating temperature: 0°C to 49°C.
Storage temperature: -20°C to 50°C.
Up to 93% relative humidity (non-condensing).

Certifications
FCC ID: 2AAJXQS-IQPANEL4
IC ID: 11205A-QSIQPANEL4
UL/ULC: UL-985, UL-1023, UL-2610, ULC-S545, ULC-S304
